Franke · A-Line coffee machine
Franke A300 FM
Compact machine for offices and lower-volume venues, producing up to 120 cups per day.
- up to 120
- Cups per day
- 8"
- Screen
- 465–545×270–340×587
- Dimensions (H×W×D), mm
- 23 kg
- Weight
Official Franke warranty · Service within 4 hours
The difference is in the details. Every one improves the cup.
Standard on this model: FoamMaster, EasyClean. Optional: Franke Digital Services, an extra grinder. We configure the machine around your venue.
Specifications
- Output
- up to 120 cups/day
- Per year
- up to 20 000 cups
- Milk system
- FoamMaster
- Milk cooler
- SU03 EC (3 l) or SU05 EC (5 l)
- Cleaning
- EasyClean
- Grinders
- up to 2
- Touch screen
- 8"
- Beverage spout
- fixed, 175 mm high
- Water connection
- mains water or a 4.8 l internal tank
- Dimensions (H×W×D)
- 465–545 × 270–340 × 587 mm, depending on configuration
- Weight
- 23 kg
- iQFlow™
- not available
- Iced Coffee Module
- not available
- Franke Digital Services
- optional
- Cups per hour (DIN 18873)
- espresso 124, cappuccino 92, coffee 80
- Parallel mode
- espresso 163, cappuccino 131, coffee 92
- Hot water per hour
- 96 cups
- Dimensions without hopper extension
- 270×465×587 mm on mains water, 340×465×587 mm with the tank
- Dimensions with hopper extension
- 270×545×587 mm on mains water, 340×545×587 mm with the tank
- Power supply
- 220–240 V 1L+N+PE, 2.1–2.3 kW (10 A); 110–127 V and 100 V configurations also available
- Bean hoppers
- without extension 1×0.5 kg or 2×0.25 kg; with extension 1×1.1 kg or 2×0.55 kg, lockable
- Powder dosing units
- one or two of 0.5 kg, lockable
- Internal water tank
- 4.8 l
- Water supply
- metal hose G3/8", 1500 mm
- Water pressure
- 0.8–8.0 bar
- Water flow rate
- over 0.1 l/s
- Water temperature
- up to 25 °C
- Water hardness
- 4–8 °dH total, 3–6 °dH carbonate
- Water pH
- 6.5–7.5
- Chlorine in water
- up to 0.5 mg/l
- Drain
- hose Ø16 mm, 2000 mm
- SU03 EC cooling unit
- 3 l, 200×445×466 mm, 14.5 kg
- SU05 EC cooling unit
- 5 l, 270×445×475 mm, 20 kg
- AC125 CL payment system
- 125×150×310 mm, 2 kg; or integrated in the SU03
- Steam wand
- MS EC models only
- Flavor Station
- not available for the A300
Drink menu
Espresso · Coffee · Hot water · Cappuccino · Latte macchiato · Coffee with milk · Warm milk · Hot milk foam · Hot chocolate (optional) · Cold chocolate (optional)
Add-on units
SU03 EC (3 l) or SU05 EC (5 l) cooling unit · AC125 CL payment system, or integrated in the SU03 · Second grinder · Bean hopper extension · Direct coffee grounds ejection
